    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly

    Ask Lasest Price
    Brand Name : OTOTRI
    Model Number : AXK4060
    Supply Ability : 10000pcs/week
    Price : 0.1~100$/pcs
    Delivery Time : 5-7 days after receiving your payment
    Certification : ISO
    Payment Terms : L/C,T/T,Western Union,MoneyGram,Paypal
    • Product Details
    • Company Profile

    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly

    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    Product Description
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly

    Needle roller bearing

    1.Bearing Specifications :
    Needle roller bearings use long, thin cylindrical rollers to support radial loads. These needle rollers have a length that is
    typically three to four times its diameter. Needle roller bearings have a thinner cross section than other roller bearings and are ideal for limited-space applications that require carrying heavy loads. Drawn cup needle roller bearings have a deeply drawn, thin-walled outer ring. Caged drawn cup units contain a one-piece cage to guide and retain the rollers. Full-complement drawn cup units include the maximum number of rollers that can be retained by the outer shell. The drawn design allows for cost-effective accommodation of heavy radial loads. Needle roller and cage assemblies do not contain inner or outer rings. Instead, the self-contained bearing components work with a shaft or housing bore used as a raceway.

    2.Application of Bearing :
    1.Needle roller bearing: used in automobile engine, transmission, crawler wheel of excavator, compressor, crane, etc.2.Combined needle roller bearing is widely used in machine tools, metallurgical machinery, textile machinery, printing machinery and other mechanical equipment, and can make the mechanical system design very compact and smart.

    3.CROWNTRANS Bearing Features :
    Lower cross-section height and higher load capacity than traditional ball bearings.
    Small and compact for reduced overall machine size in light weighting efforts.
    Widely used in automobiles, motorcycles, printing presses, industrial robots, construction equipment and other demanding
    applications.
    Many styles to choose from including: radial, thrust and combined models, cam followers and roller followers..
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    P/N
    Needle Roller Bearing AXK series AXK3047 AXK4060 AXK5070 AXK6085 AXK7095 AXK75100 Large Thrust Needle Roller and Cage Assembly
    Brand
    OEM
    Precision
    ABEC-1
    Type
    Needle Roller Bearings
    Lubrication
    Oil
    Material
    Chrome Steel
    Package
    Plastic Bag and Box
    Payment Item
    T/T ,Western Union , Paypal ,Credit card
    Delivery time
    3-10day
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    OTOTRI Precision P5 AXK4060 Large Thrust Needle Roller and Cage Assembly
    Size Information
    Bearing Part No.
    Dc1
    Dc
    Dw
    AXK0414-TV
    4
    14
    2
    AXK0515-TV
    5
    15
    2
    AXK0619-TV
    6
    19
    2
    AXK0821-TV
    8
    21
    2
    AXK1024
    10
    24
    2
    AXK1226
    12
    26
    2
    AXK1528
    15
    28
    2
    AXK1730
    17
    30
    2
    AXK2035
    20
    35
    2
    AXK2542
    25
    42
    2
    AXK3047
    30
    47
    2
    AXK3552
    35
    52
    2
    AXK4060
    40
    60
    3
    AXK4565
    45
    65
    3
    AXK5070
    50
    70
    3
    AXK5578
    55
    78
    3
    AXK6085
    60
    85
    3
    AXK6590
    65
    90
    3
    AXK7095
    70
    95
    4
    AXK75100
    75
    100
    4
    AXK80105
    80
    105
    4
    AXK85110
    85
    110
    4
    AXK90120
    90
    120
    4
    AXK100135
    100
    135
    4
    AXK110145
    110
    145
    4
    AXK120155
    120
    155
    4
    AXK130170
    130
    170
    5
    AXK140180
    140
    180
    5
    AXK150190
    150
    190
    5
    AXK160200
    160
    200
    5
